Описание:
Марка:
1. Load Pressure: 1 ton
2. Max Journey: 324mm
3. Compression spring diameter:102-254mm
Features:
Hands Free foot operated hydraulic action with quick release
Smooth, long stroke hydraulic actuator
Includes two sizes of spring yokes 100mm - 158mm
Adjustable spring yokes hold the strut spring very securely.
Fitted with Safety Guard
Specifications:
Spring Coil Diameter: 10-16mm (Never exceed maximum of 16mm)
Compression Length: 210-570mm (Never exceed maximum of 570mm)
Maximum Spring Pitch: 110mm
Strut Tube Diameter: 100-160mm
Maximum Stroke: 315mm
Safety Guard Inner Diameter: 360mm
Dimensions: 1180x510x680mm
Net Weight: 38kg
