Aprašymas:
Gamintojas:
Mark
Yato
Symbol
YT-55503
Series
GRE
Kit contents
hydraulic pump | actuator | x4 extension (140, 240, 340, 590 mm) | spreading jaws | round cap | flat cap | cylinder catch | piston catch | slotted cap |
Load
10 t
Connection thread size
13 / 16-20 UNEF
Working pressure
620 bar
Stroke of the actuator piston
135 mm
The number of pieces in the set
15
Contents of the kit cd.
V-type cap | rubber cap | male connector
The operating range of the actuator
355-495 mm
Jaw strength
0.5 t
The 10-ton spreader is intended for workshop, assembly and sheet metal works requiring the application of significant static forces. The device is used for lifting, stretching, spreading, bending, straightening and stretching.
piston stroke: 135 mm
pressure: 620 bar
working range: 355-495 mm
Included:
pump for the spreader
4 extensions: 140, 240, 340, 590 mm
spreading jaws 0.5 t
8 accessories: round, flat, slotted, V-type and rubber cap, cylinder and piston attachment, male connector
