Description:
Brand:
Description
dual lifting piston
low headroom, thus particularly suitable for vehicles with low ground clearance
high mobility in connection with two oil and acid-resistant steel swivel castors
safe and precise control when lifting and lowering, simple operation with the lifting rod
compact design
two-part lever tube, bottom part with rubber protector
rubber pad made of oil-resistant rubber
front wheel dimensions: Ø 60 x 46 mm
rear wheel dimensions: Ø 60 x 30 mm
lifting pad diameter: 110 mm
Technical data
Length 648 mm
Width 344 mm
Packaging suitable for wall hanging No
Gross weight 34000 g
Lever length 1247 mm
Lifting height max. 510 mm
Lifting height min. 75 mm
Rated load capacity 3 t
