Description
7-segment display, 12.5 mm, 3.5 numbers
suitable for measurements in CAT II ranges such as household appliances with connectors, car electronics, etc.
has the most common measuring ranges:
DC voltage: 200 mV, 2000 mV, 20 V, 200 V, 600 V
AC voltage: 200 V, 600 V
direct current: 200 µA, 2000 µA, 20 mA, 200 mA, 10 A
resistance: 200 ohm, 2000 ohm, 20 kiloohm, 200 kiloohm, 2000 kiloohm
diode test
transistor test (hfe) via adaptor
battery info display shows if battery should be replaced
operating temperature: 10°C~40°C / 0~75% relative air humidity
storage temperature: -10°C~50°C / 0~75% relative air humidity
scope of delivery:
batteries
measuring cable
adaptor for transistor test
Technical data
Length 126 mm
Height 24 mm
Width 70 mm
Battery type 2 x AAA | 1,5 V
Gross weight 204 g
Weight inc. batteries 0,14 kg
Packaging suitable for wall hanging Yes
